End Panels:
All end panels are constructed of 1” nine ply hardwood plywood with premium grade veneer HPL or TFL on both faces; exposed edges are banded with 3mm solid wood or PVC edges and corners 1/8” radius.

Browser Box:
The upper browser box is 35”L x 23-3/4”W x 5-7/8”D with 3/4” thick long sides and bottom. Vertical back partition is 1” thick. Browser boxes are engineered with dowel and glue construction. Bins have (11) holes for adjusting ¼”diameter finished steel rod. All items are grade A veneer with 3mm wood edge bands, HPL with 3mm PVC edge bands or TFL with 3mm PVC edgebands.

Base:
The toe assembly is a 4” high box frame constructed of 1” thick 9 ply hardwood plywood. The toe assembly is bolted to the end and intermediate panels using 5/16” - 18 machine bolts.

Mobile Option:
A steel chassis is installed inside of the toe assembly. Casters are bolted to the chassis with 1/4”-20 bolts and nylon insert lock nuts and the entire assembly is attached to the end panel with 5/16”-18 machine bolts. The steel chassis provides formed flanges under the toe and end panels for extra support. The casters are 2” diameter, non-locking. The mobile bookcase sits 1/2” off the floor. To Specify add -MOB.

Overall Dimensions
Depth: 24"
Width: 36"
Height(s): 30", 36"
